Anwar Tubefittings, a top-notch manufacturer and supplier based in Manama, Bahrain, specializes in high-quality Stainless Steel 304 Ball Valves designed for reliable and efficient flow control in tough industrial settings. These valves are celebrated for their durability, resistance to corrosion, and adherence to international standards, ensuring leak-proof performance and longevity even under high pressure and temperature. Anwar Tubefittings takes pride in crafting each SS 304 Ball Valve with a focus on sturdy construction, precise engineering, and user-friendly operation. They are widely utilized throughout Bahrain and the Gulf region, making them perfect for applications in chemical processing, petrochemicals, oil and gas, water treatment, and instrumentation systems, all while providing safe and accurate fluid management.
The Stainless Steel 304 Ball Valves are made up of 18% chromium and 8% nickel, which gives them outstanding corrosion resistance, mechanical strength, and durability. They boast high tensile and yield strength, good ductility, and the ability to withstand wear and deformation under varying pressure and temperature. These valves maintain their shape and sealing performance over extended use, guaranteeing leak-proof operation. The precision-engineered ball and seat mechanism ensures smooth flow control and a long service life. Their blend of mechanical strength, corrosion resistance, and dependable operation makes them ideal for critical industrial and commercial applications that demand consistent performance.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
| Grade | Mn | C | Si | S | Cr | P | N | Mo | |
| 304 | minimum maximum | – 2.0 | – 0.08 | – 0.75 | – 0.030 | 18.0 20.0 | – 0.045 | – 0.10 | – |
| 304L | minimum maximum | – 2.0 | – 0.030 | – 0.75 | – 0.030 | 18.0 20.0 | – 0.045 | – 0.10 | – |
| 304H | minimum maximum | – 2.0 | 0.04 0.10 | – 0.75 | – 0.030 | 18.0 20.0 | -0.045 | – | – |
| Grade | (% in 50mm) Elongation minimum | 0.2% Proof Yield Strength (MPa) minimum | Strength of Tensile (MPa) minimum | Hardness | |
| Brinell (HB) max | Rockwell B (HR B) max | ||||
| 304 | 40 | 205 | 515 | 201 | 92 |
| 304L | 40 | 170 | 485 | 201 | 92 |
| 304H | 40 | 205 | 515 | 201 | 92 |
| Grade | British | Euronorm | UNS No. | SS | JIS | ||
| European Standards | British Standards | Name | DIN No. | ||||
| 304 | 58E | 304S31 | X5CrNi18-10 | 1.4301 | S30400 | 2332 | SUS 304 |
| 304L | – | 304S11 | X2CrNi19-11 | 1.4306 | S30403 | 2352 | SUS 304L |
| 304H | – | 304S51 | X6CrNi18-11 | 1.4948 | S30409 | – | – |
Contact us to get a quick quote for your requirement.
Full Bore Ball Valves are essential in systems where maintaining full flow capacity is vital. Their unrestricted internal diameter makes them ideal for pipelines that require minimal pressure drop, such as those used in oil and gas transmission, petrochemical processing, water and wastewater management, and district cooling networks. They are also frequently found in chemical plants, HVAC systems, power generation facilities, and marine applications. With their reliable shut-off capabilities, ease of operation, and low maintenance needs, these valves are well-suited for both high-pressure and high-temperature environments. Their durability and consistent performance make them a trusted choice across various industries.
Stainless Steel 304 Ball Valves find their place in industries that require safe, durable, and precise control of fluids or gases. They are commonly used in chemical and petrochemical plants, oil and gas pipelines, water treatment facilities, and various industrial process systems. Additionally, these valves are essential in power generation, pharmaceutical manufacturing, food and beverage processing, and instrumentation systems where leak-proof operation and corrosion resistance are crucial. SS 304 Ball Valves provide efficient shut-off and flow regulation, even under high-pressure conditions.
