Anwar Tubefittings, located in Manama, Bahrain, stands out as a top manufacturer and supplier of high-quality industrial valves, including Hydraulic SAE Flange Ball Valves. Known for their precision engineering, durability, and dependable performance, this company caters to various industries such as oil and gas, construction machinery, hydraulic systems, and industrial equipment. Their Hydraulic SAE Flange Ball Valves are expertly designed to ensure secure, leak-proof flow control in high-pressure hydraulic systems, providing tight shutoff and smooth operation. By utilizing premium materials, cutting-edge manufacturing techniques, and rigorous quality control, Anwar Tubefittings produces valves that adhere to international standards, delivering reliable solutions for challenging industrial hydraulic applications.

Hydraulic Sae Flange Ball Valve Supplier in Manama, SAE Flanged End Ball Valve Price List in Riffa , SS316 Ball Valves Manufacturer in Sitrah, Hexagon shape Hydraulic Sae Flange Ball Valve in Hamad Town, Hydraulic Sae Threaded Ball Valve Exporter in Riffa , Hydraulic Sae Compression Ball Valve Manufacturer in A'ali, Hydraulic Sae Flange Ball Valve In Manama, Bahrain.

Typically made from high-grade stainless steel, carbon steel, or alloy materials, Hydraulic SAE Flange Ball Valves boast excellent mechanical strength, corrosion resistance, and long-lasting durability. They are equipped with precision-machined spherical balls, sturdy stems, and reinforced sealing components to minimize leakage and ensure reliable operation even under high-pressure hydraulic conditions. Their mechanical properties include high tensile strength, fatigue resistance, and consistent performance despite extreme pressure and temperature changes. The SAE flange design facilitates secure, standardized connections to hydraulic piping systems.

KhpHydraulic Sae Flange Ball Valve Specification

Size Range: 1/8″ TO 2″ / 6 MM TO 50 MM
Design: Quarter Turn Type
Material: Steel / SS316
Working Pressure: 3000 PSI / 6000 PSI
Connections: SAE Flanged End, Code 61 / Code 62
Brand: TU-LOK
Applicable Medium: General Hydraulic Oil (Gas Application on request)
Temperature Range for Steel Ball Valves: -20°C to +100°C
Temperature Range for SS316 Ball Valves: -30°C to +100°C
Ball Seats: POM (POM standard option, other materials on request)
Stem and Adaptor Sealing Materials: NBR (NBR standard option, other materials on request)

Top Hydraulic Sae Flange Ball Valve Manufacturing Company in Manama

At Anwar Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Sae Flange Ball Valve in Manama, Bahrain. Our advanced manufacturing facilities, strategically positioned in the Bahrain, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands

types of ball valves

Valve Type	BKH / BKHP	MKH / MKHP	KH
Diameter Size	1/8″ to 1″	1 1/4” to 2	1/2” to 3”
Working Pressure	Up to 800 Bar	Up to 420 Bar	Up to 420 Bar
Body Design	Square shape	Round / Hexagon shape	Round shape
Connection Type	Threaded Compression Flange end	Threaded Compression Flange end	Flange end

Types of Hydraulic Sae Flange Ball Valve

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Hydraulic Sae Ball Valve Supplier In Sitrah, SAE Flanged End Ball Valve Exporter In Manama, SS316 Ball Valves Dealer In Riffa , Hydraulic Sae Hexagon shape Ball Valve Supplier in Manama, Hydraulic Sae Threaded Ball Valve Price List in Riffa , Hydraulic Sae Compression Ball Valve Manufacturer in Sitrah, Hydraulic Sae Flange end Ball Valve in Hamad Town, Hydraulic Sae Ball Valve Exporter in Riffa , Hydraulic SAE Flanged End Ball Valve Manufacturer in A'ali, Hydraulic Sae Flange Ball Valve In Manama, Bahrain.

Ball valve with SAE flange flow rate

Nominal Diameter (mm)	Nominal Diameter (inch)	Kv (m3/h)	Cv (gal/min)
15	1/2″	19,4	22,6
20	3/4″	45,6	53,0
25	1″	71,5	83,1
32	1 1/4″	105	122,1
40	1 1/2″	170	197,7
50	2″	275	319,8
65	2 1/2″	507	589,5
80	3″	905	1052,3
100	4″	1414	1644,2
125	5″	2362	2746,5
150	6″	3694	4295,3

Hydraulic Sae Flange Ball Valve Supplier in Manama, Bahrain

Anwar Tube Fittings is a leading supplier and Stockist of premium Hydraulic Sae Flange Ball Valve in Manama, Bahrain. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the fittings industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hydraulic Sae Flange Ball Valve Uses

These valves are widely utilized in oil and gas, construction, hydraulic machinery, and industrial systems where high-pressure flow control and leak-proof operation are essential. They are perfect for isolating, regulating, or controlling the flow of hydraulic fluids in pipelines and hydraulic circuits. With their robust construction, corrosion resistance, and reliable performance, Hydraulic SAE Flange Ball Valves are indispensable for engineers and operators seeking safe, efficient, and durable solutions in demanding hydraulic environments.
